Enrutador módem VDSL | FTTC | Ftts | ADSL Werss N 300Mbps

Modem Router FR(VDSL | FTTC | FTTS | ADSL) fino a 100 Mbps, Wi-Fi N300
Connettività versatile - Dotato di porta DSL e LAN/WAN, TD-W9960 è compatibile con standard di connessione VDSL2/ADSL2+/ADSL2/ADSL.
Connessioni FR (VDSL) - Supporta connessioni FR fino a 100Mbps.
Wi-Fi N300 - Velocità wireless fino a 300Mbps in 2.4GHz.
Ampia copertura - Le potenti antenne esterne offrono un'ampia copertura del segnale wireless.
Configurazione e gestione intuitiva - La potente app Tether e la pratica interfaccia web permettono di configurare e gestire la rete in pochi semplici step.

CARATTERISTICHE HARDWARE
Interfaccia3 10/100Mbps RJ45 LAN Ports
1 10/100Mbps RJ45 LAN/WAN Port
1 RJ11 Port
TastoWPS Button
RESET Button
Power ON/OFF Button
Alimentatore esterno9VDC/0.6A
Standard IEEEIEEE 802.3, 802.3u
Standard VDSL2ITU-T G.993.2
ITU-T G.993.5 (G.vector)
ITU-T G.998.4 (G.INP)
Dimensioni ( L x P x A )181.6 x 129.7 x 36.2mm
Tipo di antennaOmni directional, Fixed
Guadagno antenna2 x 5dBi
CARATTERISTICHE WIRELESS
Standard wirelessIEEE 802.11b, 802.11g, 802.11n
Frequenza2.400-2.4835GHz
Potenza di trasmissione<20dBm(EIRP)
Sicurezza wireless64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2
encryptions, Wireless MAC Filtering
CARATTERISTICHE SOFTWARE
QoS (Quality of Service)WMM, Bandwidth Control (IP QoS)
SicurezzaNAT Firewall, SPI Firewall, DoS Protection, IP & MAC Binding, Service Filtering, Access Control, Parental Controls
Modalità operativeVDSL/ADSL Modem Router, Wireless Router,
GestioneWeb Based Configuration (HTTP), Remote management, CWMP(TR-069), Web Based Firmware Upgrade, Diagnostic Tools
VPN pass-throughIPSec VPN
ProtocolliSupports IPv4 and IPv6
Protocolli ATM/PPPPPPoE (RFC2516)
PPPoA (RFC 2364)
MER\IPoE (RFC 1483 Routed)
IPoA (RFC1577/2225)
Bridge (RFC1483 Bridge)
Caratteristiche avanzateParental Controls, Network Address Translation(NAT), Port Mapping(Grouping), Static Routing, DNS Relay, DDNS, IGMP V1/V2/V3
APPTether App
NATVirtual Server, Port Triggering, DMZ, ALG, UPnP
ALTRO
CertificazioneCE, RoHS
Contenuto della confezioneTD-W9960
External DSL Splitter
RJ-11 DSL Cable
RJ-45 Ethernet Cable
Quick Installation Guide
Power Adapter
Requisiti di sistemaMicrosoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10,
Mac OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Subscription with an internet service provider (for internet access)
AmbienteOperating Temperature: 0?~40?(32?~104?)
Storage Temperature: -40?~70?(-40?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
